| Description |
Application |
Qty |
Part # |
| 10-32 x 1/2" socket |
Bumpers, Nerf, wing stand and torque tube hoop |
12 |
4321 |
| 1/4-20 x 1/2" button |
wing valve to frame |
2 |
6080 |
| 1/4-28 x 5/8" |
front wing strap to sideboard, acc. Pedal, oil tank mount |
9 |
1528 |
| 1/4-28 x 7/8" button |
fuel plate |
12 |
5203 |
| 5/16-24 x 1 1/2" |
front wing strap to frame |
2 |
1296 |
| 1/4-28 x 1 1/2" |
throttle bell crank |
1 |
1281 |
| 5/16-18 x 3/4" socket |
side mount fuel tank |
4 |
3857 |
| 5/16-18 x 1 ¼ socket |
bell retainer to bell housing |
4 |
3859 |
| 5/16-18 x 1 ¼ button |
inboard rear brake rotor bolts |
8 |
5246 |
| 3/8-24 x 2 |
brake pedal to frame |
1 |
1313 |
| 5/16-24 x 1 3/4 |
wing front post |
4 |
1297 |
| 5/16-24 x 1 |
steering mount |
2 |
1294 |
| 5/16-24 x 2 1/4 |
brake pedal to heim on master cyl., master cyl. to frame |
3 |
3710 |
| 3/8-24 x 1 3/4 |
wing tree to wing and frame |
4 |
1312 |
| 3/8-24 x 1 |
steering clamp, front motor plate to frame |
4 |
1309 |
| 3/8-24 x 1 |
caliper to caliper bracket |
2 |
1309 |
| 3/8-16 x 1 |
bell housing to torque plate, engine to motor plate |
10 |
1106 |
| 3/8 x 1 ½ pin |
ladder to clevis |
1 |
5104 |
| 3/8-16-24 x 2 stud |
torque tube to rear end |
6 |
6042 |
| 3/8-24 x 2 |
front and rear stops and arms pinch, pitman pinch |
9 |
1313 |
| 3/8-24 x 2 |
wing cylinder to tree |
1 |
1313 |
| 3/8-24 x 2 1/2 |
rear motor plate to frame |
4 |
1314 |
| 3/8-16 x 2 1/2 |
engine block to frame and motor plate (top) |
2 |
1111 |
| 3/8 x 3 ¾ pin |
w-link clevis pins |
2 |
5101 |
| 7/16-20 x 2 hex |
adjuster stop bolts |
4 |
5100 |
| 7/16-14 x 1 1/2 |
Inboard brake to rear end |
2 |
1125 |
| 1/2-20 x 1 ½ flange |
radius rod to birdcage |
2 |
4997 |
| 1/2-20 x 1 1/2 |
fronts and rear top shock to frame |
6 |
1345 |
| 1/2-20 x 1 1/2 |
rt frt steering arm to spindle |
2 |
1345 |
| 1/2-20 x 2 |
tie rod and drag link |
4 |
1348 |
| 1/2-20 ONS with spacer |
lower rear shock |
2 |
5110 |
| 1/2-20 x 2 3/4 |
radius rods and panhard bar |
6 |
1533 |
| 1/2-20 x 1 3/8 |
front radius rods to axle |
3 |
6022 |
| 1/2-20 x 2 countersunk |
combo arm to spindle |
2 |
6029 |
| 1/2-20 x 3/4 countersunk |
front brake rotor |
3 |
6038 |
| 7/16-20 x 2 Al Jam nuts |
|
4 |
6049 |
| 1/2-20 nylocks |
|
15 |
6012 |
| 1/2" thin washers |
|
3 |
6000 |
| 3/8-24 Jet lock nuts |
|
24 |
1544 |
| 3/8 thin washers |
|
24 |
6002 |
| 5/16-24 half ht nylock (jet) |
|
11 |
1543 |
| 5/16 washers |
|
20 |
6004 |
| 1/4-28 lock nuts (jet) |
|
10 |
1542 |
| 1/4" washers |
|
10 |
6005 |
| 1/2" Rue Clip |
|
1 |
5435 |
| 5/16-18 all-metal locknuts |
|
8 |
6017 |
| 10-32 jet nuts |
|
12 |
1541 |
| 3/8" rue clip |
|
2 |
5436 |
